Type T118 - Globe Valve

Applications:

Approved for air gases, vapours and cryogenic liquefied gases incl. LNG.

Working temperature: -196°C / -321°F (77K) up to +65°C / 149°F (338K)

Ambient temperature: -40°C / -40°F (233K) up to +65°C / 149°F (338K)

Maximum operating pressure: 50bar

Cryogenic Globe Valves with check unit, PN50

suitable for CombiPressure-Regulator type 4182/4186

"¦cleaned and degreased for oxygen service¦"

Part No. T118.X.1A0C0

Male thread for union connection

Available options - on request only:

· Butt weld connection for stainless steel pipes acc. to ISO 1127 or ASTM A312

· Union type butt weld fittings for stainless steel pipes acc. to ISO 1127 or ASTM A312

· Union type braze fittings for copper pipes acc. to DIN EN 12449 or ASTM B88

· Thread connection NPT acc. to ANSI B 1.20.1
